BP93420-IQT High Temperature Resistance Flush Pressure Transmitter Sensor for Hygienic Applications with Fast Response Speed and Long Service Life

BP93420-IQT High Temperature Resistance Flush Pressure Transmitter Sensor for Hygienic Applications with Fast Response Speed and Long Service Life
BP93420-IQT High Temperature Resistance Flush Pressure Transmitter Sensor for Hygienic Applications with Fast Response Speed and Long Service Life
Temel bilgi
En iyi fiyat Şimdi başvurun
Detay Bilgi
Vurgulamak:

Hygienic Applications Pressure Transmitter Sensor

,

Fast Response Speed Flush Pressure Sensor

,

Long Service Life Pressure Transducer

Ürün Açıklaması

BP93420-IQT Hengtong 4-20mA High Temperature Resistance Flush Pressure Transmitter Sensor
The BP93420-IQT features a 1.5mm clamp installation with large diaphragm high temperature transmitter. Its signal processing circuit is housed in stainless steel, converting sensor signals into standard output signals. Designed for environments requiring high sanitary conditions, this pressure transmitter ensures reliable and accurate measurements in hygienic applications.
Key Features
  • High precision measurement
  • Simple installation process
  • No direct medium contact
  • Excellent corrosion resistance
  • Strong anti-interference capability
  • High temperature adaptability
  • Multiple output signal options
  • Extended service life due to non-contact design
Applications
  • Measurement of non-corrosive gases and liquids with 316L compatibility
  • Environmental protection and chemical industries
  • Marine and aviation applications
  • Medical, biopharmaceutical, and food hygiene industries
Performance Specifications
Parameter Specification
Measurement Range 0~35Kpa…~3.5MPa
Pressure Type Gauge Pressure, Absolute Pressure, Sealed Pressure
Overload ≤ 1.5 times of the rated range
Accuracy @ 25ºC ±0.25% (Typical) ±0.5% (Maximum)
Repeatability 0.1%FS
Hysteresis 0.1%FS
Long-Term Stability ±0.1%F.S/Year(Typical) ±0.2%F.S/Year(Maximum)
Zero Point Temperature Drift ±0.02%F.S/ºC(≤100KPa) ±0.01%F.S/ºC(>100KPa)
Full Scale Temperature Drift ±0.02%F.S/ºC(≤100KPa) ±0.01%F.S/ºC(>100KPa)
Frequency Response 2.4Khz
Compensation Temperature -20-70ºC(≤10mpa,customizable)
Operating Temperature -20ºC~80ºC
Storage Temperature -40ºC~120ºC
Vibration 10g,55Hz ~ 2kHz
Housing Material 304,316L
Diaphragm Material 316L
Insulation Resistance 100MΩ 100VDC
Explosion-proof Rating Ex db IIC T6 Gb
Protection Rating IP65
O-Ring Seal Fluoro rubber
Weight ~0.55kg
Output Signal Options
Output Signal Supply Voltage Output Type
4~20mA 12~30VDC 2/3/4 wire
0~10/20mA 3 wire
0/1~5V
0/1~10V
0.5~4.5V		 5VDC
RS485 Communication Protocol 3.6~30V / Battery 4 wire
BP93420-IQT High Temperature Resistance Flush Pressure Transmitter Sensor for Hygienic Applications with Fast Response Speed and Long Service Life 0 BP93420-IQT High Temperature Resistance Flush Pressure Transmitter Sensor for Hygienic Applications with Fast Response Speed and Long Service Life 1 BP93420-IQT High Temperature Resistance Flush Pressure Transmitter Sensor for Hygienic Applications with Fast Response Speed and Long Service Life 2 BP93420-IQT High Temperature Resistance Flush Pressure Transmitter Sensor for Hygienic Applications with Fast Response Speed and Long Service Life 3
Ordering Information
Product Code Structure
Code Outline Construction
IB General Pressure Transmitter
IX Display Pressure Transmitter
IE Shock-resistant Aviation Pressure Transmitter
IIC/III Industrial General/Display Pressure Transmitter
IF Moisture-proof Pressure Transmitter
IIE/IIIE General/Display Pressure Transmitter
IN Air Conditioning Dedicated Pressure Transmitter
IC High-temperature Pressure Transmitter
IQ/IQT Large Diaphragm /High-temperature Pressure Transmitter
Measurement Range Options
-100kPa…0kPa ~ 35kPa…3.5MPa (0-X)Kpa or MPa where X indicates the actual measuring range
Power Supply Options
Code Power Supply
D1 24VDC
D2 5VDC
D3 Other
Output Signal Options
Code Output Signal
S1 4~20mADC
S2 1~5VDC
S3 0~5VDC
S4 0~10mADC
S5 0~20mADC
S6 0~10VDC
S7 0.5~4.5VDC
Electrical Connection Options
Code Connection Type
B1 Hirschmann
B2 PG7 Plug
B3 Sealed Cable Output
B4 2088 Industrial Casing
B5 2088 Industrial Casing with Display
B6 Other
Pressure Type Options
Code Pressure Type
G Gauge Pressure
A Absolute Pressure
S Sealed Reference Pressure
Ordering Guidelines
  • Ensure medium compatibility with product contact parts
  • Note that explosion-proof models exclude digital display heads
  • For LCD/LED displays, power supply should be ≥20VDC
  • Install lightning protection devices and ensure proper grounding
  • Fluoro rubber O-ring operates between -20ºC to 250ºC (use EPDM for lower temperatures)
  • Default cable length is 1.5m (polyethylene material)
  • Specify special requirements (vibration, impact, EMI/RFI) when ordering
Frequently Asked Questions
  • Q: What are the features of your pressure sensor transmitters?
    A: High precision, durability, and excellent performance. Customization available.
  • Q: Can I customize special specifications?
    A: Yes, our engineers can tailor products to meet specific needs. We provide OEM and ODM service.
  • Q: What is your production capacity?
    A: Up to 30,000 units/month. Contact sales for large orders.
  • Q: What's the typical delivery period?
    A: 5-8 working days for standard models (custom products may vary).
  • Q: How are the products priced?
    A: Competitive pricing with bulk order discounts available.
  • Q: What is the warranty and after-sales service?
    A: 24-month warranty with 24-hour response time for support queries.
